Model NO.
1x24 plc splitter
Price:
US $ 7.80-8.50 / piece
Delivery:
FOB
Minimum order quantity:
1 piece
Supply Ability:
1000 piece / Week
Country of Origin:
china
Quantity:

FTTH Optical 1 24 Way Box Optical PLC 1x24 Fiber Optic Splitter

Product Description

product description



Professional custom all kinds of optical fiber branching device (cassette miniature cone inserted chip) 1, 2, 1, 4, 1 points 8 16, 32, 2 points, 1 points, 2, 2, 2, 4, 2 points 16 minutes and 32 fiber optical splitter can customize any length according to customer demand, customized various joint: FC, SC, ST, LC, etc., the client may choose any material: G652D, G657A1, G657A2, PVC, UPC, PC, APC, etc., can also be customized according to customer requirements and drawing processing.

Parameters1×21×41×81×161×321×641×128
Operating Wavelength(nm)1260~1650
Fiber TypeG657A1 or customer specified
Insertion Loss (dB)(P/S Grade)3.8/4.07.1/7.310.2/10.513.5/13.716.5/16.920.5/21.023.8/24.2
Loss Uniformit(dB)0.40.60.81.21.52.02.5
Polarization Dependent Loss(dB)0.20.20.20.250.30.350.4
Return Loss(dB)(P/S Grade)55/5055/5055/5055/5055/5055/5055/50
Directivity(dB)55555555555555
Wavelength Dependent Loss(dB)0.30.30.30.50.50.50.5
Temperature Stability (-40~85℃)(dB)0.40.40.40.50.50.50.5
Operating Temperature(℃)-40~+85
Storage Temperature(℃)-40~+85
Device Dimension(mm)40×4×440×4×440×4×450×7×450×7×460×12×4N/A
Module Dimension(mm)100×80×10120×80×18141×115×18
Mini-Module Dimension(mm)50×7×460×12×480×20×6100×40×6N/A

Company Information

company informationcertifications

  • Place of Origin:China
  • Brand Name:WTT
