ITEM
Technical Parameters
Connector type
SC;FC;LC
Applicable for
Indoor cable 0.9mm,2.0mm,3.0mm; Drop cable(2.0*3.0mm)
Optical fiber diameter
125μm(SM&APC); 127um(MM)
Fiber mode
Single mode(G657A);Miltimode(OM1,OM2,OM3,OM4)
Polishing Type
UPC ; APC
Operation time
About 120s(no fiber cut)
Insert loss
≤ 0.5dB(1310nm & 1550nm)
Return loss
≥50dB
Fastening strength of naked fiber
>5 N
Fastening strength of naked fiber holder
>10 N
Tensile strength
>50 N
Using temperature
-40~+75℃
C50K
0.00~0.00
