GJXFH FTTH Drop Cable
GJXFH
Small bending fatigue lifetime is several hundred times longer than all standard single mode fiber.
Quantity:
FTTH fiber optic cable is designed for use FTTH systems. Small diameter, light, can be used in many situations. Simple structure, anti press, anti pull, anti aging. Small bending fatigue lifetime is several hundred times longer than all standard single mode fiber. The cable complete with black flame retardant LSZH outer jacket.
Features
- Suitable for limited space field of the branch, indoor series;
- Laid to facilitate construction operations;part and the cable;
- Jacket use low smoke, halogen-free flame-retardant materials;
- Prevent lightning and strong electric environment;
- FRP strengthen the component materials.
Technical Parameter
| Cable Type | Outder Sheath Diameter | Nominal Weight(kg/km) | Tensile Strength(N) | Crush Load(N/100mm) | Bending Radius(mm) | |||
| Short term | Long term | Short term | Long term | Dynamic | Static | |||
| GJXFH | 2.0 (±0.1) *3.0mm (±0.1) | 8.0kg+/-1kg | 40 | 80 | 1000 | 500 | 20D | 10D |
| Storage/Working temperature | -20℃~+70℃ | |||||||
