Fiber Optic Stripping Machine
Fiber Optic Stripping Machine
Fiber Optic Stripping Machine

Fiber Optic Stripping Machine

Model NO.
WTC
Quantity:

Structure description and working principle

The main frame of the machine adopts its own innovative and unique technical scheme, which makes the whole machine light and easy to operate, and conforms to ergonomics. The surface is anodized, thus improving the corrosion resistance of metal surface exposed to air for a long time. The parts with high machine rigidity requirements are made of steel, chrome plated on the surface to ensure that the machine is not corroded and durable; the external shield is made of 304 stainless steel by sheet metal processing; the electric box surface is sprayed with environmental protection paint, safe and non-toxic. The whole machine material conforms to RoHS standard.

The machine is mainly powered by compressed air, and the whole operation process is controlled by single chip microcomputer to finish the processing process of peeling, shearing and aramid. So that the original 3 processing procedures to complete the work, on the machine can be easily completed in one step (no skilled workers),Greatly improve the production efficiency, and the product consistency is good.



Specification

Length and width height(mm)Net weightElectric source power ratingAir pressureYield
425X220X300 mm24 KgAC 220V20W0.5~0.6Mpa>900pcs/H
