Model NO.
WT06C
Quantity:

12 24 Fibers IP65 Horizontal Optical Fiber Splice Closure with PLC Splitter

WT06 is a small size fiber optic splice closure that made of high quality ABS material. It is used for fiber optic cable splicing and protection. The external component and fastening piece are all made of the high-quality steel. It can be opened after sealing.


Dimension

281.6x200.3x88.5mm

Number of entry/exit ports

2 or 3pcs

Diameter of fiber cable

Φ8mm~φ12mm

Capacity per splice tray

6 fibers; 12 fibers if 2 fiber per slot

Qty of splice tray

2~4pcs

Max. capacity

24 fibers or 48 fibers

Adapter plate

FC, SC, LC, ST … adapter

PLC splitter

1pc PLC splitter 1x2, 1x4, 1x8, 1x16

Temperature

-40℃ to +65℃.

IP standard

IP65
