Shenzhen Wirenet Telecom Technology Co., Ltd.518116About UsRoom 202, 2rd floor, 2 Building,Jingheyuan Industry Park,No.2004 Banxuegang Road, Bantian Street, Longgang District, Shenzhen, ChinaShenzhen Wirenet Technology Co., Ltd, has 10 years’experience on manufacturing and supplying fiber optic cabling system products.
Our production base including 7000m2of fiber optic cable and patch cord workshop; 2000m2of fiber optic connector and adapter workshop, and 1000m2 fiber optic PLC splitter workshop, and a 700m2 of head office with Fiber optic testing Lab.Shenzhen Wirenet Telecom Technology Co., Ltd.518116About UsRoom 202, 2rd floor, 2 Building,Jingheyuan Industry Park,No.2004 Banxuegang Road, Bantian Street, Longgang District, Shenzhen, ChinaShenzhen Wirenet Technology Co., Ltd, has 10 years’experience on manufacturing and supplying fiber optic cabling system products.
Our production base including 7000m2of fiber optic cable and patch cord workshop; 2000m2of fiber optic connector and adapter workshop, and 1000m2 fiber optic PLC splitter workshop, and a 700m2 of head office with Fiber optic testing Lab.Shenzhen Wirenet Telecom Technology Co., Ltd.Shenzhen Wirenet Telecom Technology Co., Ltd.Shenzhen Wirenet Telecom Technology Co., Ltd.Shenzhen Wirenet Telecom Technology Co., Ltd.She
Connector A: LC | Connector B: LC |
Fiber Mode: 9/125 μm | Fiber Count: Duplex |
Fiber Grade: G.652D/G.657A2 | Minimum Bend Radius:30 mm |
Polish Type: APC | Cable Diameter: 3.0mm |
Cable Jacket: PVC/LSZH | Jacket Color: Yellow |
Wavelength:1310 nm/1550 nm | Durability:>1000 Times |
Insertion Loss:≤0.25 dB | Interchangeability:≤0.2 dB |
Return Loss:≥55 dB | Vibration:≤0.2 dB |
Operating Temperature:-40~85°C | Storage Temperature: -40~85°C |
Specification
Items | Single mode | Multimode |
PC | UPC | APC | 62.5/125 | 50/125 | 50/125 10G/40G |
Insertion Loss | <0.2dB | <0.3dB |
Return Loss | ≥45dB | ≥50dB | ≥60dB | ≥35dB |
Durability | <0.1dB typical change, 500 matings |
Operation temperature | -40~+75(℃) |
Ferrule hole size | 125.0+1/-0um, Conentricity:≤1um | 125um,Conectricity:1≤3um |
125.0+1/-0um, Conentricity:≤1um | 127um,Conectricity:1≤3um |
125.5+1/-0um, Conentricity:≤1um | 128um,Conectricity:1≤3um |
126.0+1/-0um, Conentricity:≤1um |
Order information
Related Products
Model NO. LC DX 2.0mm Patch Cord
Model NO. SC DX 3.0mm Patch Cord
Model NO. SC DX 2.0mm Patch Cord
