Connector A: LC
Connector B: LC
Fiber Mode: 9/125 μm
Fiber Count: Du plex
Fiber Grade: G.652D/G.657A2
Minimum Bend Radius: 30 mm
Polish Type: UPC
Cable Diameter: 3.0 mm
Cable Jacket: PVC/LSZH
Jacket Color: Yellow
Wavelength: 1310 nm/1550 nm
Durability: >1000 Times
Insertion Loss: ≤0.25 dB
Interchangeability: ≤0.2 dB
Return Loss: ≥55 dB
Vibration: ≤0.2 dB
Operating Temperature: -40~85°C
Storage Temperature: -40~85°C
Specification Items
Single mode
Multimode
PC
UPC
APC
62.5/125
50/125
50/125 10G/40G
Insertion Loss
<0.2dB
<0.3dB
Return Loss
≥45dB
≥50dB
≥60dB
≥35dB
Durability
<0.1dB typical change, 500 matings
Operation temperature
-40~+75(℃)
Ferrule hole size
125.0+1/-0um, Conentricity:≤1um
125um,Conectricity:1≤3um
125.0+1/-0um, Conentricity:≤1um
127um,Conectricity:1≤3um
125.5+1/-0um, Conentricity:≤1um
128um,Conectricity:1≤3um
126.0+1/-0um, Conentricity:≤1um
Order information
